Constant Pressure Inverter Pump
Fosen Constant Pressure Inverter Pump is highly efficient and energy-saving, operates at a continuous stable pressure, and is widely used in household and commercial water systems to meet different water needs. Intelligent regulation can extend the life of the equipment.
Send Inquiry
Product Description
Constant Pressure Inverter Pump
Constant pressure control
Variable frequency pumps can automatically adjust the water supply according to water demand, maintain constant pipe pressure, and ensure water supply efficiency and user requirements for water pressure.
Energy saving
Through variable frequency speed regulation technology, variable frequency pumps can significantly reduce shaft power while meeting water demand, achieving energy and water conservation. The energy saving rate can generally reach 20% -50%.
Adjustable
The pressure can be set according to actual usage needs, and can also be converted to 50/60Hz.
Self protection
Equipped with comprehensive fault self checking and power-off self recovery processing functions.
PARAMETER
| Voltage: 220V | Frequency: 50-60Hz |
| Liquild: Clean Water | Max suction: 8m |
| Insulation Class: Class F | Protection Class: IPX4 |
| Liquild Temperature: 0-90°C | Ambient Temperature: 0-45°C |
CONSTANT PRESSURE
INVERTER PUMP
Model Description
Product Performance Chart
Product Parameter
| Model |
Voltage (V/Hz) |
Power (w) |
Current (A) |
Max.Head (m) |
Max.Flow |
Rated Head (m) |
Rated Flow |
Suction (m) |
Pipe Size (mm) |
Recommend Floor&below |
Gross Weight (kg) |
Carton Size (mm) |
||
| (m³h) | (L/min) | (m³/h) | (L/min) | |||||||||||
| WZB35-400I | 220/50~60 | 400 | 2.7 | 35 | 2.3 | 38.4 | 15 | 1.0 | 16.7 | 8 | 25 | 4 | 12.0 | 380x280x380 |
| WZB40-600I | 220/50~60 | 600 | 4.2 | 40 | 3.2 | 53.4 | 22 | 1.5 | 25 | 8 | 25 | 6 | 15.4 | 380x280x380 |
| WZB45-800I | 220/50~60 | 800 | 5.2 | 45 | 3.5 | 58.5 | 28 | 1.5 | 25 | 8 | 25 | 8 | 16.3 | 380x280x380 |
| WZB60-1500I | 220/50~60 | 1500 | 10.0 | 60 | 6.0 | 100.2 | 35 | 3 | 50.1 | 8 | 40 | 12 | 24.3 | 380x280x380 |
Mounting Dimensions (mm)
| Model | C | E | H | L | W |
| WZB35-400I | 163.5 | 141 | 251 | 274 | 120 |
| WZB40-600I | 190 | 148 | 275 | 290 | 148 |
| WZB45-800I | 190 | 148 | 275 | 290 | 148 |
| WZB60-1500I | 229 | 179 | 328 | 328 |
150 |
